| Embedded control board | ✔ Came ZN8 |
|---|---|
| Maximal weight of gate leaf | 2500 kg |
| Maximum lenght of gate leaf | 20 m |
| Power supply | 230V AC, 50/60 Hz |
| Power supply - engine | 36V DC |
| Cycles per hour | Continuous operation |
| Power | 300 W |
| Standby power consumption | 14 W |
| Thrust | 1000 N |
| Maximum thrust | 1500 N |
| Current draw | 10 A |
| Maximum current draw | 20 A |
| Maximum operating speed | 12 m / minute |
| Synchronous operating with second motor | ✔ |
| Pinion module | 6 |
| Protection rating | IP54 |
| Housing color | RAL 7024 |
| Operating temperature | -20°C ÷ +55°C |
| Weight | 21 kg |
| Dimensions | 400 × 260 × 412 mm |
